TStaticTextDemo 项目分析

项目信息

• 项目名称: TStaticTextDemo
• 下载链接: TStaticTextDemo.rar
• 分析时间: 2026-03-05

文件结构

TStaticTextDemo/
├── Extractor_Icon.ico
├── Project1.py
├── Project1.xml
├── Unit1.py
├── Unit1.pydfm
├── Unit1.sct
├── Unit1.sfm

主程序文件: Project1.py

from glcl import *
from Unit1 import *

def main():
    Application.Initialize()
    Application.Title = 'Project1'
    Application.MainFormOnTaskbar = True
    Application.Icon.LoadFromFile(os.path.join(os.path.dirname(os.path.abspath(__file__)), "Extractor_Icon.ico"))
    MainForm = Form1(Application)
    MainForm.Show()
    FreeConsole()
    Application.Run()
    MainForm.Free()

if __name__ == '__main__':
    main()

单元文件: Unit1.py

import os
from glcl import *

class Form1(Form):

    def __init__(self, owner):
        self.LoadProps(os.path.join(os.path.dirname(os.path.abspath(__file__)), "Unit1.pydfm"))
        self.StaticText1.OnDblClick = self.StaticText1DblClick

        # 创建 TStaticText 对象
        self.static_text = StaticText(self)
        self.static_text.Parent = self  # 设置父控件
        # 设置静态文本的位置和大小
        self.static_text.Left = 50      # 距离左侧50个像素
        self.static_text.Top = 50       # 距离顶部50个像素
        self.static_text.Width = 300     # 宽度300个像素
        self.static_text.Height = 50      # 高度50个像素
        # 设置静态文本的内容
        self.static_text.Caption = "欢迎使用 TStaticText 控件！"

    def StaticText1DblClick(self, Sender):
        ShowMessage('OnDblClick')

设计文件: Unit1.sct

def StaticText1DblClick(Sender):

设计文件: Unit1.sfm

object Form1: TForm
  Left = 0
  Top = 0
  Caption = 'Form1'
  ClientHeight = 278
  ClientWidth = 397
  Color = clBtnFace
  Font.Charset = DEFAULT_CHARSET
  Font.Color = clWindowText
  Font.Height = -15
  Font.Name = 'Segoe UI'
  Font.Style = []
  TextHeight = 20
  object StaticText1: TStaticText
    Left = 32
    Top = 160
    Width = 85
    Height = 24
    BorderStyle = sbsSunken
    Caption = 'Hello World'
    Color = clWindow
    Font.Charset = DEFAULT_CHARSET
    Font.Color = clBlack
    Font.Height = -15
    Font.Name = 'Segoe UI'
    Font.Style = []
    ParentColor = False
    ParentFont = False
    TabOrder = 0
    OnDblClick = StaticText1DblClick
  end
end

其他文件

• Extractor_Icon.ico
• Project1.xml

详细分析

功能概述

GUI组件演示

使用的组件

• Form1 (TForm)
• StaticText1 (TStaticText)

技术特点

• 包含2个GUI组件
• 定义0个事件处理

窗体属性

• caption: Hello World
• height: 278
• width: 397

代码分析

导入的模块: - import os - from glcl import *

定义的类: - Form1

定义的方法: - init - StaticText1DblClick

---
