TActionListDemo 项目分析¶

项目信息¶

项目名称: TActionListDemo
下载链接: TActionListDemo.rar
分析时间: 2026-03-05

文件结构¶

TActionListDemo/
├── Extractor_Icon.ico
├── Project1.py
├── Project1.xml
├── Unit1.py
├── Unit1.pydfm
├── Unit1.sct
├── Unit1.sfm

主程序文件: Project1.py¶

from glcl import *
from Unit1 import *

def main():
    Application.Initialize()
    Application.Title = 'Project1'
    Application.MainFormOnTaskbar = True
    Application.Icon.LoadFromFile(os.path.join(os.path.dirname(os.path.abspath(__file__)), "Extractor_Icon.ico"))
    MainForm = Form1(Application)
    MainForm.Show()
    FreeConsole()
    Application.Run()
    MainForm.Free()

if __name__ == '__main__':
    main()

单元文件: Unit1.py¶

import os
from glcl import *

class Form1(Form):

    def __init__(self, owner):  # 构造函数，接收一个参数 owner
        self.ListBox1 = ListBox(self)
        self.PopupMenu1 = PopupMenu(self)
        self.MainMenu1 = MainMenu(self)
        self.ActionList1 = ActionList(self)
        self.LoadProps(os.path.join(os.path.dirname(os.path.abspath(__file__)), "Unit1.pydfm"))
        # 注意：动作是选中ActionList然后右键弹出菜单选择Action List Editor创建
        self.actClear.OnExecute = self.actClearExecute  # 绑定清空动作的执行方法
        self.actDelete.OnExecute = self.actDeleteExecute  # 绑定删除动作的执行方法
        self.actAdd.OnExecute = self.actAddExecute  # 绑定添加动作的执行方法

    def actAddExecute(self, Sender):  # 添加水果的执行方法
        newFruit = Application.InputBox('请输入水果名', '水果', '')  # 弹出输入框请求水果名
        self.ListBox1.Items.Add(newFruit)  # 将输入的水果名添加到列表框中

    def actDeleteExecute(self, Sender):  # 删除水果的执行方法
        selIndex = self.ListBox1.ItemIndex  # 获取选中的列表项索引
        if selIndex != -1:  # 如果有选中项
            self.ListBox1.Items.Delete(selIndex)  # 从列表中删除选中的项
        else:  # 如果没有选中项
            Application.MessageBox('当前未选中水果', '提示', MB_ICONINFORMATION)  # 显示提示信息

    def actClearExecute(self, Sender):  # 清空列表的执行方法
        self.ListBox1.Clear()  # 清空列表框中的所有项

设计文件: Unit1.sct¶

def actAddExecute(Sender):
def actDeleteExecute(Sender):
def actClearExecute(Sender):

设计文件: Unit1.sfm¶

object Form1: TForm
  Left = 0
  Top = 0
  Caption = 'Form1'
  ClientHeight = 338
  ClientWidth = 490
  Color = clBtnFace
  Font.Charset = DEFAULT_CHARSET
  Font.Color = clWindowText
  Font.Height = -15
  Font.Name = 'Segoe UI'
  Font.Style = []
  Menu = MainMenu1
  TextHeight = 20
  object ListBox1: TListBox
    Left = 24
    Top = 24
    Width = 441
    Height = 257
    ItemHeight = 20
    Items.Strings = (
      #33529#26524
      #39321#34121
      #33889#33796
      #30707#27060
      #30058#33540
      #21704#23494#29916
      #26586#23376
      #24067#26519
      #35199#29916)
    PopupMenu = PopupMenu1
    TabOrder = 0
  end
  object ActionList1: TActionList
    Left = 456
    Top = 296
    object actAdd: TAction
      Caption = #22686#21152#27700#26524
      OnExecute = actAddExecute
    end
    object actDelete: TAction
      Caption = #21024#38500#27700#26524
      OnExecute = actDeleteExecute
    end
    object actClear: TAction
      Caption = #28165#31354#27700#26524
      OnExecute = actClearExecute
    end
  end
  object MainMenu1: TMainMenu
    Left = 392
    Top = 296
    object MenuItem5: TMenuItem
      Caption = 'MenuItem5'
      object MenuItem10: TMenuItem
        Caption = 'MenuItem10'
      end
    end
    object MenuItem4: TMenuItem
      Caption = 'MenuItem4'
      object MenuItem9: TMenuItem
        Caption = 'MenuItem9'
      end
    end
    object MenuItem3: TMenuItem
      Caption = #32534#36753
      object MenuItem8: TMenuItem
        Action = actAdd
      end
      object MenuItem16: TMenuItem
        Action = actDelete
      end
      object MenuItem17: TMenuItem
        Action = actClear
      end
    end
    object MenuItem2: TMenuItem
      Caption = 'MenuItem2'
      object MenuItem7: TMenuItem
        Caption = 'MenuItem7'
      end
    end
    object MenuItem1: TMenuItem
      Caption = 'MenuItem1'
      object MenuItem6: TMenuItem
        Caption = 'MenuItem6'
      end
    end
  end
  object PopupMenu1: TPopupMenu
    Left = 424
    Top = 296
    object MenuItem11: TMenuItem
      Action = actAdd
    end
    object MenuItem12: TMenuItem
      Action = actDelete
    end
    object MenuItem13: TMenuItem
      Action = actClear
    end
  end
end

其他文件¶

Extractor_Icon.ico
Project1.xml

详细分析¶

功能概述¶

GUI组件演示

使用的组件¶

Form1 (TForm)
ListBox1 (TListBox)
ActionList1 (TActionList)
actAdd (TAction)
actDelete (TAction)
actClear (TAction)
MainMenu1 (TMainMenu)
MenuItem5 (TMenuItem)
MenuItem10 (TMenuItem)
MenuItem4 (TMenuItem)
MenuItem9 (TMenuItem)
MenuItem3 (TMenuItem)
MenuItem8 (TMenuItem)
MenuItem16 (TMenuItem)
MenuItem17 (TMenuItem)
MenuItem2 (TMenuItem)
MenuItem7 (TMenuItem)
MenuItem1 (TMenuItem)
MenuItem6 (TMenuItem)
PopupMenu1 (TPopupMenu)
MenuItem11 (TMenuItem)
MenuItem12 (TMenuItem)
MenuItem13 (TMenuItem)

技术特点¶

包含23个GUI组件
定义0个事件处理

窗体属性¶

caption: MenuItem6
height: 338
width: 490

代码分析¶

导入的模块: - import os - from glcl import *

定义的类: - Form1

定义的方法: - init - actAddExecute - actDeleteExecute - actClearExecute
