TPanelDemo 项目分析

项目信息

• 项目名称: TPanelDemo
• 下载链接: TPanelDemo.rar
• 分析时间: 2026-03-05

文件结构

TPanelDemo/
├── Extractor_Icon.ico
├── Project1.py
├── Project1.xml
├── Unit1.py
├── Unit1.pydfm
├── Unit1.sct
├── Unit1.sfm

主程序文件: Project1.py

from glcl import *
from Unit1 import *

def main():
    Application.Initialize()
    Application.Title = 'Project1'
    Application.MainFormOnTaskbar = True
    Application.Icon.LoadFromFile(os.path.join(os.path.dirname(os.path.abspath(__file__)), "Extractor_Icon.ico"))
    MainForm = Form1(Application)
    MainForm.Show()
    FreeConsole()
    Application.Run()
    MainForm.Free()

if __name__ == '__main__':
    main()

单元文件: Unit1.py

import os
from glcl import *

class Form1(Form):

    def __init__(self, owner):
        self.Button1 = Button(self)
        self.Panel1 = Panel(self)
        self.LoadProps(os.path.join(os.path.dirname(os.path.abspath(__file__)), "Unit1.pydfm"))
        self.Button1.OnClick = self.Button1Click

        # 创建 TPanel 控件
        self.panel = Panel(self)  # 创建面板并设置其拥有者为当前窗口
        self.panel.Parent = self  # 设置面板的父控件
        self.panel.Caption = 'This is a TPanel'  # 设置面板标题
        self.panel.Align = alTop  # 设置面板对齐方式为顶部
        self.panel.Height = 100  # 设置面板高度
        self.panel.Color = clBtnFace  # 设置面板背景颜色

        # 创建一个 TButton 控件
        self.button = Button(self.panel)  # 创建按钮并设置其拥有者为当前窗口
        self.button.Parent = self.panel  # 设置按钮的父控件
        self.button.Caption = 'Show Message'  # 设置按钮标题
        self.button.Width = 150
        self.button.Left = 20  # 设置按钮左边距
        self.button.Top = 20  # 设置按钮上边距
        self.button.OnClick = self.on_button_click  # 绑定按钮点击事件

    def on_button_click(self, sender):
        # 处理按钮点击事件
        ShowMessage('Hello from TPanel!')  # 在面板上显示消息


    def Button1Click(self, Sender):
        ShowMessage(self.Panel1.Caption)

设计文件: Unit1.sct

def Button1Click(Sender):

设计文件: Unit1.sfm

object Form1: TForm
  Left = 0
  Top = 0
  Caption = 'Form1'
  ClientHeight = 348
  ClientWidth = 382
  Color = clBtnFace
  Font.Charset = DEFAULT_CHARSET
  Font.Color = clWindowText
  Font.Height = -15
  Font.Name = 'Segoe UI'
  Font.Style = []
  TextHeight = 20
  object Panel1: TPanel
    Left = 16
    Top = 152
    Width = 345
    Height = 177
    Caption = 'Panel1'
    TabOrder = 0
    object Button1: TButton
      Left = 24
      Top = 136
      Width = 75
      Height = 25
      Caption = 'Button1'
      TabOrder = 0
      OnClick = Button1Click
    end
  end
end

其他文件

• Extractor_Icon.ico
• Project1.xml

详细分析

功能概述

GUI组件演示

使用的组件

• Form1 (TForm)
• Panel1 (TPanel)
• Button1 (TButton)

技术特点

• 包含3个GUI组件
• 定义2个事件处理

窗体属性

• caption: Button1
• height: 348
• width: 382

代码分析

导入的模块: - import os - from glcl import *

定义的类: - Form1

定义的方法: - init - on_button_click - Button1Click

事件绑定: - self.Button1.OnClick = self.Button1Click - self.button.OnClick = self.on_button_click # 绑定按钮点击事件

---
